Emerson A6500-UM Universal Measurement Card
Product Details:
Brand Name | Emerson |
Model | A6500-UM |
Condition | NEW |
Gross weight | 2.1kg |
Packing size | 20*15*10cm |
Payment Term | T/T |
Warranty | 1 year |
Courier Partner | DHL, UPS, TNT, FedEx and EMS |
Description:
The Emerson A6500-UM Universal Measurement Card is a versatile core component for machinery health monitoring systems, designed to integrate diverse signals from diverse industrial sensors.
It supports multiple input types—including vibration, displacement, and speed sensors—with high-precision data acquisition. The 3U single-slot design ensures space efficiency, while hot-swappable functionality simplifies maintenance.
Compliant with API 670 standards, it operates reliably in harsh environments and seamlessly connects to Emerson’s AMS 6500 system via internal bus. Equipped with self-diagnostic features and flexible output options (4-20mA, digital), it enables real-time monitoring and predictive maintenance for turbines, compressors, and critical rotating equipment in energy and manufacturing sectors.
General Features:
o Input Channels: 2 sensor input channels (independent or combined based on measurement mode)Sensor Types Supported:由o Eddy-current
o Piezoelectric (accelerometer or velometer)
o Seismic(electrodynamic)
o Low Frequency(LF)bearing vibrationo Hall-effect
o LVDT(with A6500-LC)Digital l/0: 5 digital inputs and 6 digital outputs.中
o Signal Processing: Signals are transmitted through an internal RS-485 bus to the A6500-CC Com Card.
o Communication Protocols: Modbus RTU and Modbus TCP/lP for data transmission to host systems.
o USB Connectivity: Configuration and visualization of results through the USB socket on the A6500-CC Com Cardo Analog Output: 0/4- 20 mA, with common ground and electrical isolation from system supply.
